4

Spline

1 1/2 - 28

1 1/2 - 28

1 1/2 - 10

1 1/2 - 10

Kit

815806

815807

815808

815809

Clevis Size

5/8 - 1/2

5/8 - 1/2

5/8 - 1/2

5/8 - 1/2

Arm Length

5 - 6

5 1/2 - 6 1/2

5 - 6

5 1/2 - 6 1/2

Slack Adjuster

815787-NSS

815788-NSS

815789-NSS

815790-NSS

Bracket

815803

815803

815803

815803

Spline

1 1/2 - 28

Arm Length

5 1/2

Clevis Size

1/2

Kit

815810

Slack Adjuster

815791-NSS

Bracket

815803

Spline

1 1/2 - 28

1 1/2 - 28

1 1/2 - 10

1 1/2 - 10

Arm Length

6

5 1/2 - 6 1/2

6

7

Clevis Size

1/2

1/2

1/2

1/2

Kit

815811

815812

815813

810473

Slack Adjuster

815792-NSS

815793-NSS

815794-NSS

810465-NSS

Bracket

815804

815804

815804

810466

Spline

1 1/2 - 28

Arm Length

6

Clevis Size

1/2

Kit

815829

Slack Adjuster

815828-NSS

Bracket

807567

Bracket 815803

Bracket 810466Bracket 815804

Drive Axle Application

NSS - Not sold seperately . . . order kit

Mack

(With Air Ride

Suspension)

Disc

(Rockwell)

Mack Truck
