14

STRAIGHT

OFFSET

Yoke Offset

Adapter

Thread

Size

‘B’

Arm

Length

‘A’

Spline Size

(Diameter and

Number of Teeth)

Lube

Fitting

All offset slack

adjusters are

provided as shown.

If the opposite

offset is needed

remove the yoke

and rotate 180°.

The most commonly used

adapter is supplied

with the slack

adjuster, alternate

adapters must be

purchased separately.

Bendix

®

ASA-5

™

SureStroke

™

Slack Adjuster

Yoke

Link

ASA-5

™

EXTERIOR
