INSPECT EC-11

™

CONTROLLER

FOR ILLUMINATED LED(S)

NOTE ILLUMINATED

LED(S) AND GO TO

SECTION III-

INSPECTION FOR

ILLUMINATED RED

LED(S)

GO TO SECTION

VII - FALSE FAIL-

URE INDICATION

GO TO SECTION IV -

TESTING FOR POWER TO

EC-11

™

CONTROLLER

REPLACE EC-11

™

CONTROLLER

AND REPEAT

STARTUP

CHECK FOR

GREEN (PWR)

LED

YES

GREEN (PWR)

LED ON

ARE ANY RED

LEDS ON?

GREEN (PWR)

LED OFF

NO

YES

NO

ARE

ANY

ON?

ARE ANY RED

LEDS ON?

TROUBLESHOOTING

SECTION II INSPECTION FOR ILLUMINATED LEDS

ON?
